Eclisse Single Classic Pocket Door Kit

SKU:

Save space with the Eclisse sliding pocket door system the perfect alternate solution to traditional hinged doors. Ideal for en-suites, downstairs toilets, bathrooms, utility rooms, store rooms, pantries, walk-in robes, basically any room where you wish to save space. You would just need to add your own timber door (35 or 44mm in the appropriate size), plasterboard, and final decorative architrave to complete your pocket door solution.

Choosing the right sizeData Sheet | Studwork Guide

Need further help or something bespoke?Contact our knowledgeable customer service team.

Optional Accessories with this kit:



FREE mainland UK delivery with every pocket door kit, for non-mainland areas please contact us - Note timber door not included with the kit.

Lead time - Stock Line - Order before 1 pm for next working day delivery

Door Panel Size
Finished Wall Thickness
Door Panel Size
610 x 1981mm (2'0" x 6'6")

Finished Wall Thickness
95mm

IN STOCK
£298.80
INC VAT
Be the first to leave a review - Click Here

What is included:

Galvanised steel frame

Strong galvanised steel frame.  A quick-click frame that assembles into a complete unit comprising of a full pocket and a track.

Runners

Runners are tested to 100,000 cycles (that’s around 25 years of average use!)

Extractable Track

Track can be extracted without having to break into the wall. (See Tech Tips section in Technical tab for instructions).

Front and rear door stop

Can be adjusted to determine how far the door protrudes from the pocket.

Metal anti-warp door profile

Slots into a channel in underside of door. Not visible but ensures that if your door warps it continues to slide smoothly.

Self centering door guide

Clicks into frame, doesn't screw into the floor, so it is perfectly centred every time.

Fixings

Even the screws to attach the plasterboard to the frame are included.

Jamb kit

Comes complete with jamb kit made with a beechwood veneer* that is unfinished and paint/stain ready. The jamb kit includes dustbrushes and recessed door post with integral bumpers for a professional finish. What is a jamb kit? View explanation and see parts list here
We reserve the right to supply jambs with alternative wood/finish*





Further technical information:

DOOR PANEL WEIGHT:

100kg (150kg available on request)

BESPOKE SIZING AVAILABLE?:

Yes- Max door panel width 2026mmm; Max door panel height 2910mm (only currently available in 100 & 125mm finished wall thickness other sizes coming soon)

DOOR THICKNESS:

35 - 44mm

FINISHED WALL THICKNESS:

95, 100, 115, 125mm or 140mm (90mm frame double boarded)

SYSTEM TYPE:

For use with timber doors

JAMB KIT SUPPLIED?:

Yes- the jamb kit made comes with a beechwood veneer* that is unfinished and paint/stain ready.

DOOR SUPPLIED?:

No- you can use a standard UK or ROI  door panel size



Guarantee

15-year guarantee on the complete Eclisse steel pocket system and runners.

Brand Eclisse
Fire Rating None Fire Rated Kit
Single or Double Kit Single
Frame Design Visible - finished with architrave
DescriptionGet File
Eclisse Single Classic Pocket Door Kit - Data Sheet DOWNLOAD
70 - 90 Single Classic Door Installation Guide DOWNLOAD
70 - 90mm Single Classic Frame Installation Guide DOWNLOAD
75 - 100mm Single Classic Frame and Door Installation Guide DOWNLOAD
Pocket Door Studwork Guide DOWNLOAD
